Belt Feeder

Functional Features:

1. Bulk materials can be selected and fed using a belt feeder.

1. It features a compact design, quick changeover, and low noise operation.

2. It offers high versatility and is compatible with multi-pin components.

3. Working Principle: Components are selected via a sorting track. NG (Non-conforming) materials are recirculated. Belt Recirculation: Selected components are transported to the pick-up location by a linear vibrator.

4. It can be mounted on SMT machines of any brand, enabling the feeding of bulk materials without the need for packaging, thereby saving packaging costs.
