| Model | LL-512 |
| Dimension (L x W x H) | 1200 x 700 x 1600 mm |
| Processing Efficiency | 1300pcs/h (100mmL) |
| Wire Dimension Range | AWG #32 - AWG #18 |
| Processing Length | Mid-span Conductor Exposure: 10mm - 99999mm |
| Stripping length | 0.1mm-15mm |
| Compressed Air | 0.4~0.8MPa |
| Crimping Capacity | 1.5 Ton |
| Detection Functions | Terminal presence detection, wire insertion detection, crimp quality inspection. |
| Auxiliary Device | Terminal Waste Paper Winding Unit |
| Power Supply | AC 220V |
| Machine Weight | Approx. 360 kg |
| Brand of Main Components | HIWIN (Taiwan) linear guide rails, Airtac (Taiwan) cylinders & solenoid valves, Leadshine closed-loop + servo motors, HIWIN (Taiwan) linear guide rails, imported Japanese bearings. |
